560-580 Series N-type Double Glass Cell Solar Panel

Product Description

560-580W 22.45% 0.55%

POWER RANGE MAXIMUM EFFICIENCY YEARLY DEGRADATION

12 YEARS PRODUCT WARRANTY 30 YEARS OUTPUT GUARANTEE

The difference between p-type and n-type crystalline solar cells

The raw material that precedes the the pulling and cutting of silicon wafers is the same for both p and n-type cells. This raw silicon feedstock is “grown” into ingots (Czochralski process) or cast as bricks and then thinly sliced. These wafers form the basis of a solar cell. It is at this point that p and n-type cells diverge. To create a semiconductor junction that will induce current flow the wafers are doped (coated) with either boron (p-type) or phosphorus (n-type).

ELECTRICAL CHARACTERISTICS 丨 STC*

Nominal Power Watt Pmax(W)*	560	565	570	575	580
Power Output Tolerance Pmax(%)	0~+3	0~+3	0~+3	0~+3	0~+3
Maximum Power Voltage Vmp(V)	41.95	42.14	42.29	42.44	42.59
Maximum Power Current Imp(A)	13.35	13.41	13.48	13.55	13.62
Open Circuit Voltage Voc(V)	50.67	50.87	48.32	51.27	51.47
Short Circuit Current Isc(A)	14.13	14.19	14.25	14.31	14.37
Module Eﬃciency (%)	21.68	21.87	22.07	22.26	22.45

MECHANICAL DATA

Solar cells	Double glass
Cells orientation	144（6×24）
Module dimension	2278×1134×30mm (With Frame)
Weight	32 kg
Glass	3.2mm, High Transmission, AR Coated Tempered Glass
Junction box	IP 68，3 diodes
Cables	4 mm² ,350 mm (With Connectors)
Connectors*	MC4-compatible

ELECTRICAL CHARACTERISTICS 丨 NMOT

Maximum Power Pmax(Wp)	421	425	429	432	436
Maximum Power Voltage Vmpp(V)	39.39	39.52	39.65	39.78	39.87
Maximum Power Current Impp(A)	10.69	10.75	10.81	10.87	10.94
Open Circuit Voltage Voc(V)	48.13	48.32	48.51	48.70	48.89
Short Circuit Current Isc(A)	11.41	11.46	11.50	11.55	11.60

**TEMPERATURE RATINGS* WORKING CONDITIONS**

NMOT	45℃ ±2℃	Maximum system voltage	1500 V DC
Temperature coeﬃcient of Pmax	-0.25%/℃	Operating temperature	-40℃~+85℃
Temperature coeﬃcient of Voc	-0.25%/℃	Maximum series fuse	30 A
Temperature coeﬃcient of Isc	+0.045%/℃	Front Side Maximum Static Loading Up to 5400 Pa
Refer.Bifacial Factor	80±5%	Rear Side Maximum Static Loading Up to 2400 Pa

Double-sided generation parameters (back gain)

5%	Maximum Power (PMAX)	588	593	599	604	609
5%	Component efficiency (%)	22.77	22.97	23.17	23.37	23.57
15%	Maximum Power (PMAX)	644	650	656	661	667
15%	Component efficiency (%)	24.93	25.15	25.37	25.37	25.82
25%	Maximum Power (PMAX)	700	706	713	719	725
25%	Component efficiency (%)	27.10	27.34	27.58	27.82	28.07
