MBB technology reduce the distance between busbars and finger grid line which is benefit to power increase.
Better Weak Illumination Response
More power output in weak light condition, such as haze,cloudy, and early morning.
Anti PID
Ensured PID resistance through the quality control of cell manufacturing process and raw materials.
Adapt To Harsh Outdoor Environment
Resistant to harsh environments such as salt, ammonia, sand, high temperature and high humidity environment.
TIER 1
Global,Tier 1 bankable brand,with independently certified advanced automated manufacturing.
Bifacial Technology
up to 25% additional power gain from back side depending on albedo.
Excellent Quality Managerment System
Warranted reliability and stringent quality assurances well beyond certified requirements.
ELECTRICAL CHARACTERISTICS 丨 STC*
|
Nominal Power Watt Pmax(W)* |
435 |
440 |
445 |
450 |
455 |
460 |
|
Power Output Tolerance Pmax(%) |
0~+3 |
0~+3 |
0~+3 |
0~+3 |
0~+3 |
0~+3 |
|
Maximum Power Voltage Vmp(V) |
34.00 |
34.20 |
34.40 |
34.60 |
34.80 |
35.00 |
|
Maximum Power Current Imp(A) |
12.80 |
12.87 |
12.94 |
13.01 |
13.08 |
13.15 |
|
Open Circuit Voltage Voc(V) |
40.90 |
41.10 |
41.30 |
41.50 |
41.70 |
41.90 |
|
Short Circuit Current Isc(A) |
13.55 |
13.62 |
13.69 |
13.76 |
13.83 |
13.90 |
|
Module Efficiency (%) |
20.16 |
20.39 |
20.62 |
20.85 |
21.08 |
21.32 |
MECHANICAL DATA
|
Solar cells |
Mono PERC |
|
Cells orientation |
120（6×20） |
|
Module dimension |
1903×1134×30mm (With Frame) |
|
Weight |
26.5±1.0 kg |
|
Glass |
2.0 mm+2.0mm, High Transmission, AR Coated Heat Strengthened Glass |
|
Junction box |
IP 68，3 diodes |
|
Cables |
4 mm² ,350 mm |
|
Connectors* |
MC4-compatible |
ELECTRICAL CHARACTERISTICS 丨 NMOT*
|
Maximum Power Pmax(Wp) |
325.30 |
328.80 |
332.60 |
336.30 |
340.10 |
343.80 |
|
Maximum Power Voltage Vmpp(V) |
31.60 |
31.80 |
32.00 |
32.10 |
32.30 |
32.50 |
|
Maximum Power Current Impp(A) |
10.29 |
10.34 |
10.40 |
10.46 |
10.52 |
10.58 |
|
Open Circuit Voltage Voc(V) |
38.20 |
38.40 |
38.60 |
38.80 |
39.00 |
39.10 |
|
Short Circuit Current Isc(A) |
10.94 |
11.00 |
11.06 |
11.11 |
11.17 |
11.23 |
TEMPERATURE RATINGS WORKING CONDITIONS
|
NMOT |
44℃ ±2℃ |
Maximum system voltage |
1500 V DC |
|
Temperature coefficient of Pmax |
-0.35%/℃ |
Operating temperature |
-40℃~+85℃ |
|
Temperature coefficient of Voc |
-0.29%/℃ |
Maximum series fuse |
30 A |
|
Temperature coefficient of Isc |
0.05%/℃ |
Front Side Maximum Static Loading Up to 5400 Pa Rear Side Maximum Static Loading Up to 2400 Pa |
|
|
Refer.Bifacial Factor |
70±5% |
|
|
